PENBERTHY LIQUID LEVEL GAUGE
Deskripsi
Model Type: RL/RM/TL/TM MODEL GAGES:
Gauge Type: 320/420 P
Sections: One through four
Glass Size; One through nine
Wetted : Carbon Steel chamber material
Connections: 1/2″ and 3/4″ NPT ends and sides
Gaskets: Grafoil with Mylar insert, Nobestos® or Teflon®
Cushions: Grafoil with Mylar insert, Nobestos® or Teflon®
Paint : Standard
Hardware: Grade B7 Alloy Steel.
Shields: Mica shields
Optional : NACE MR-01-75 gages; No welds included
RH/TH GAGES
Sections: One and two
Glass Size: Four through nine
Option : Same as above
VALVES
Wetted : Steel and STS
Trim: Standard
Optional : NACE MR-01-75 valves; No welds included
Series 320/420 Series 330/430
Connections: 1/2 x 1/2 1/2 x 1/2
3/4 x 1/2 3/4 x 1/2
3/4 x 3/4 3/4 x 3/4
REPLACEMENT GASKETS Standard sizes 1-9
REPLACEMENT GLASS Borosilicate glass sizes 1-9 both reflex and transparent glass
GAGE & VALVE ASSEMBLIES Gages & Valves assembled on centers in 1/2 & 3/4 Schedule 80 carbon
steel threaded connection only.
